Integral T process thermostats
12 Brief instructions YAWE 0026 / 21.01.2019
2 Brief instructions
These brief instructions are intended to provide you with a quick introduction to
operating the equipment. For reliable operation of the thermostats it is however
absolutely essential that you read carefully the full Operating Instructions and observe
the safety notes!
1. Set up the equipment and add further items as appropriate ( Section 6.1).
The unit may NEVER be overturned nor put upside down!
Note the details on the hose connections ( Section 6.2 and 6.4).
2. Fill the equipment with the appropriate heat transfer liquid ( Section 6.4). The equipment is
designed for operation with non-flammable and flammable liquids to DIN EN 61010-2-010. Note
liquid level! ( Section 6.2)
The T 4600 (W), T 7000 (W) and T 10000 (W) should not be filled with pure water, but
only with a water-glycol mixture (minimum 70 % : 30 %) or Kryo 30!
3. Connect the equipment only to a supply socket with protective earth contact. Check the details on
the rating label against the supply voltage.
Set the overtemperature switch-off point to a value clearly above ambient
temperature ( Section 7.8.1).
5. Switch on the equipment or
6. The function “Manual Start” (display STArt) is activated. To start the unit and enter the basic menu,
press the key .
