Lauda Integral T 7000 W User Manual

Integral T process thermostats
21/01/2019 / YAWE 0026 Starting up 55
7.6.4.3 Outflow temperature limit
High limit (TiH)
 The temperature set here limits the outflow
temperature. Especially with external control this
limitation avoids the undesirable permanent switch-off
through the safety circuit (overtemperature) during the
start-up phase.
Low limit (TiL)
 The temperature set here limits the outflow
temperature against excessively low values, e.g. in
order to prevent freezing up.
 Input of a value for TiH which is below the value for TiL
causes to appear “END Err” as error message at menu
end.
 The values for TiH and TiL are entered only after
leaving the submenu.

Lauda Integral T 7000 W Specifications

General

Brand	Lauda
Model	Integral T 7000 W
Category	Thermostat
Language	English
