Integral T process thermostats
21/01/2019/ YAWE 0026 Technical Data 97
T 4600
T 4600 W
T 7000
T 7000 W
T 10000
T 10000 W
Working temperature range
°C
-30 120 (-30 150 option enlarged temperature range)
Ambient temperature range
°C
5 40
Setting resolution
K
0.1
Temperature measurement
Pt100 outflow temperature and connection for external Pt100 via Lemo
connector Gr.1
Indication resolution
K
0.05
Indication accuracy
0.2 K. additive recalibration
Temperature stability
K
± 0.2
± 0.2
± 0.3
± 0.3
± 0.3
± 0.3
Safety fittings
FL (suitable for flammable and non-flammable liquids)
Display
2-line LC display with various symbols
Cooling control
automatic compressor control, proportional cooling
Cooling capacity (eff.) with
ethanol @ 20 °C
ambient temperature resp.
15 °C cooling water
temperature
20 °C
0 °C
-10 °C
-20 °C
-30 °C
kW
kW
kW
kW
kW
4.6
2.8
1.9
1.0
0.2
5.5
3.4
2.3
1.1
0.3
7.0
5.0
3.0
1.7
0.5
8.5
5.5
3.9
2.0
0.6
10.0
7.3
5.1
3.0
1.2
13.0
8.7
6.0
3.7
1.5
Pump type external circuit
side-channel immersion pump
Pump type internal circuit
Centrifugal immersion pump
Pressure measurement
bar
0 - 7, digital display of pump pressure, adjustable bypass
Pump connection
G3/4" pipe thread, 15 mm
i.d. for 3/4" hose
G1¼" pipe thread, 20 mm i.d., for 1" hose
Noise level (1 m)
maximum discharge pressure;
maximum flow rate
Pump 3.2 bar; 40 L/min
dB(A)
63
61
---
---
---
---
Pump 5.5 bar; 40 L/min
dB(A)
67
65
---
---
---
---
Pump 6.0 bar; 60 L/min
dB(A)
---
---
65
63
69
67
Internal volume
L
6 18
8 20
Protection
---
IP 32
Condenser cooling
Air
Water
max. 25 °C
Air
Water
max. 25 °C
Air
Water
max. 25 °C
Airflow rate
m³/h
2250
---
2600
---
3600
---
Power dissipated to air
kW
max. 7.1
1.2
max. 12.5
ca. 1.5
17
ca.1.5
Cooling water connections
--
3/4"
--
3/4
--
1”
Cooling water consumption
L/h
--
0/200
1000
--
0/500
1800
--
0/600
2500
Cooling water pressure
bar
--
> 2.5 10
--
> 2.5 10
--
> 2.5 10
Dimensions (W x D x H)
mm
550 x 650 x
970
550 x 650 x
970
850 x 670 x
970
850 x 670 x
970
1050 x 770
x
1120
850 x 670 x
970
Weight
kg
123
128
175
180
235
242
Protection class
Protection Class 1 to DIN EN 61140
Heater power rating / power
consumption
@ 400 V; 3/N/PE~50 Hz
kW
6.0 / 8.5
6.0 / 8.3
6.0 / 11.5
6.0 / 11.2
9.0 / 16.0
9.0 / 15.5
Heater power rating / power
consumption
@ 208 V; 3/PE~60 Hz
kW
6.0 / 8.5
6.0 / 11.5
---
---
---
---
