3 Preparations
3.1 Charging X-431 PADII
Choose any one of the followings to charge your X-431 PADII:
A. Use the included 5V power adaptor: Connect one end of the power
adaptor to DC IN port of X-431 PADII, then connect the other end to
the AC outlet. Never use other similar adaptors to charge X-431
PADII.
B. Use the docking station: Follow the steps described as below to
charge your X-431 PADII:
Locate the charging slot on the bottom of X-431 PADII tablet and 1.
the docking station. See Fig. 3-1 & Fig. 3-2.
Fig. 3-1 Fig. 3-2
Align the charging slots, and then dock the tablet into the station to 2.
ensure that it rmly sits on the docking station. Refer to Fig. 3-3.
Fig. 3-3
Insert one end of the included power cord of the docking station 3.
into the power jack, then plug the other end into the AC outlet. If
appears on the screen, it indicates it is being charged.
If the logo changes into 4.
, it indicates that the battery is fully
charged. Disconnect the docking station from the AC outlet.
3.2 On Using Your Battery
If the battery keeps unused for a long time or battery is completely •
discharged, it is normal in case it can not be turned on while being
charged. Please charge it for a period and then turn it on.
Please use the included power adaptor to charge your X-431 •
PADII. We assume no responsibility for damage or loss resulting
from using other similar adaptors other than the specied one.
The charging time of battery varies with temperature condition and •
battery consumption status.
While X-431 PADII has low battery, a beep will sound. If it is very •
low, X-431 PADII will be switched off automatically.
