X-431 PADII User's Manual
19
5-16.
Fig. 5-16
To return to the previous screen, tap
.
5.6.1 Read Trouble Code
Tap “Read Trouble Code” in function menu, the screen will display the
diagnostic result.
On-screen Buttons:
Vehicle Selection: Tap it to return to the vehicle selection screen.
Search: Tap it to search the denition of the selected DTC online.
Report: To save the current data in text format.
Print: Tap it to print the current screen. To perform printing, you need
to purchase a Wi-Fi printer manufactured by LAUNCH separately.
Help: Tap it to view the help information.
Tap
to return to the function selection screen.
5.6.2 Clear Trouble Code
Tap “Clear Trouble Code” function menu, the system will automatically
delete the currently existing trouble code.
Note: The trouble code will not disappear until the trouble was
completely cleared.
5.6.3 Read Data Stream
Tap “Read Data Stream” in function menu, the system will display data
stream items.
Fig. 5-17
On-screen Buttons:
Select Page: Tap it to select all items of the current page.
Unselect: Tap it to deselect all data stream items.
Vehicle Selection: Tap it to return to the vehicle selection screen.
Print: Tap it to print the current screen. To perform printing, you need
to purchase a Wi-Fi printer manufactured by LAUNCH separately.
Conrm: Tap it to conrm and jump to the next step.
