Installing the optional hard disk drive
The recorder does not include an HDD as standard. To install the optional 3.5”
SATA HDD, perform the following steps:
1.
Remove the nine (9) screws from the
rear of the recorder as shown.
2.
Carefully remove the back panel and
disconnect the fan cable as shown.
3.
Slide the casing off as shown.
4.
Remove the securing screw from the
HDD tray and slide the tray in the
direction shown.
