Tel: (86)755-26434369 52 Website: www.leadshine.com
CABLE-PC
Description
Special RS232 cable designed to setup communication between the drive and
PC-based configuration & tuning software ProTuner.
Order
Standard Accessory, one is enough for a user to configure and tune multiple
drives.
STU-ACS
Description
Handheld configuration & tuning unit.
Order
Optional Accessory, one is enough to configure and tune multiple drives.
CABLE-STU
Description
Special RS232 cable designed to setup communication between drive and
Handheld configuration & tuning unit STU-ACS.
Order One STU-ACS needs at least one.
A
A
C
C
S
S
6
6
0
0
6
6
D
D
i
i
g
g
i
i
t
t
a
a
l
l
A
A
C
C
S
S
e
e
r
r
v
v
o
o
d
d
r
r
i
i
v
v
e
e
M
M
a
a
n
n
u
u
a
a
l
l
R
R
e
e
v
v
1
1
.
.
0
0
Tel: (86)755-26434369 53 Website: www.leadshine.com
6 pin Control signal Connector
Description
Self-locked connector for control signals include PUL+, PUL-, DIR+ and DIR-,
ENA+，ENA-.
Order
Standard Accessory, shipped with the drive for free.
CABLE-BLM-WIND
Description
Lengthening cable for power leads between the drive and Leadshine BLM
series DC brushless servo motor.
Order
Optional Accessory, Leadshine provides 1.2m, 2.2m, 5m, 10m cable for user
selection. Users can select the proper length according to their needs.
Pin Color
Signal Description
1
Red U
Motor phase U
2
Blue V
Motor phase V
Wires
3
Black W
Motor phase W
