Leakwise SLC-220 - Page 85

95
120
67
21
41.30
297 REF.
398 REF.
372
320
346
124.50
6.5(x4)
STATUS LIGHTS
LCD
BEZEL
LCD
191
141
TRANSPARENT COVER
HINGE(x2)
WEATHERPROOF SEAL
LATCH(x2)
ENCLOUSURE TYPE: FIBOX CAB PC 403018T
NOTE: LCD IS OPTIONAL.
MATERIAL:
FINISH:
DATE
DRAWING NUMBER:
ASLC0021
1:5
SCALE:
SHEET
OF 1 1
TITLE:
SLC-220/MULTI
IP-65/N4 ENCLOSURE
SIZE
A3
WT.
QT.:
1
DD/MM/YY
TREATMENT:
.
P.C.
TOLERANCES UNLESS
OTHERWISE SPECIFIED
LINEAR
ANGULAR
SURFACE FINISH
BREAKEDGES
0.2
1
N7
0.2x45
DATE
NAME
DESIGN
DRAWN
CHECK
APPROV
H. K.
H. K.
H. K.
H. K.
17/02/15
17/02/15
17/02/15
17/02/15
USED ON: SLC-220/MULTI
DESCRIPTION DATE
APPR BY REV
DD/MM/YY
H. KOREN
ECR. No.
GE
Water & Process Technologies
Analytical Instruments
