Leakwise SLC-220 - Page 86

77.72
47.75
41
41 41
41
41
47.75
440 REF.
237 REF.
25
20.50
400mm BETWEEN MOUNTING SCREWS
COVER HINGE (X2)
1" NPT (x2)
(ONE WALL) .
3/4" NPT (x7)
(ONE WALL)
66
33
185
M3
10mm(x2)
16 TYP FOR MOUNTING SCREW
413 REF.
565 REF.
358.78
BETWEEN MOUNTING SCREWS
GLASS WINDOW 133
FRONT PANEL BENEATH
PLACE FOR S.S. TAG.
PROJECT: BP Husky
NOTES:
* THREADS SUPPLIED WITHOUT CABLE ENTRIES.
* ALL THREADS ARE CLOSED WITH CERTIFIED PLUGS.
*SEALING: NEMA 4.
*ENCLOSURE MATERIAL: COPPER FREE ALUMINIUM ALLOY.
MATERIAL:
FINISH:
DATE
DRAWING NUMBER:
CSLC70030
1:5
SCALE:
SHEET
OF 1 1
TITLE:
SLC-220-
N7/MULTI
SIZE
A3
WT.
QT.:
1
DD/MM/YY
TREATMENT:
.
ADALET CAT. NO.:
XCE 121808 N4
TOLERANCES UNLESS
OTHERWISE SPECIFIED
LINEAR
ANGULAR
SURFACE FINISH
BREAKEDGES
0.2
1
N7
0.2x45
DATE
NAME
DESIGN
DRAWN
CHECK
APPROV
H. KOREN
H. KOREN
H. KOREN
H. KOREN
20/10/15
20/10/15
20/10/15
20/10/15
USED ON:
SLC-220-
N7/MULTI
DESCRIPTION DATE
APPR BY REV
DD/MM/YY
H. KOREN
ECR. No.
GE
Water & Process Technologies
Analytical Instruments
