14–8
CURSORS/MEASURE & Parameters
MEASURE — Parameters — Custom
In this mode, up to five parameters can be displayed for various
traces.
Off/Cursors/Parameters
For selecting “Parameters”.
mode
To select “Custom” parameters.
statistics
For turning “On” display of the parameter’s average, lowest, highest,
and standard deviation, as well as the number of sweeps included in
the statistics — cleared each time the acquisition conditions change
or when the CLEAR SWEEPS button is pressed.
As long as “Parameters” is highlighted in the top menu, the
accumulation of statistics continues, even if the statistics are not
shown.
CHANGE PARAMETERS
For accessing the secondary “CHANGE PARAM” menu (see
following pages).
from
To determine the starting point, in screen divisions, for parameter
measurements. “Track” “On”, links control of both the starting and
end points of the parameter measurement so that they can be
moved together using the associated menu knob.
to
To determine the end point in screen divisions.
To Next Page
