WaveJet 300A Series
10 917976 Rev A
Table 2-3. List of <compound command program header>
Selectable Depth1 Element Selectable Depth2 Element
C1, C2, C3, C4 and M1 VDIV Command/Query
C1, C2, C3, C4 and M1 OFST Command/Query
C1, C2, C3, C4 and M1 TRA Command/Query
C1, C2, C3 and C4 CPL Command/Query
C1, C2, C3 and C4 PROBE Command/Query
C1, C2, C3 and C4 BWL Command/Query
2.7 Buffer size limitations related to block data
• If data exceeding the input buffer limit is received, the excess data is discarded until a delimiter is detected.
• If data exceeding the output queue limit is transmitted, commands that are not interpreted and excess data
are discarded.
2.8 List of <PROGRAM DATA> elements
These may appear within an <expression>, and maximum sub-expression nesting depth.
Table 2-4. List of <PROGRAM DATA> elements
Element Implemented?
<CHARACTER PROGRAM DATA> Yes
<DECIMAL NUMERIC PROGRAM DATA> Yes
<SUFFIX PROGRAM DATA> Yes (see Figure 2-1)
<NON-DECIMAL NUMERIC PROGRAM DATA> No
<STRING PROGRAM DATA> No
<ARBITRARY BLOCK PROGRAM DATA> Yes
<EXPRESSION PROGRAM DATA> No
2.9 Response syntax for every query.
Table 2-5. Device listening functional elements
Element Implemented?
<RESPONSE MESSAGE> Yes
<RESPONSE MESSAGE TERMINATOR> Yes
<RESPONSE MESSAGE UNIT> Yes
<RESPONSE MESSAGE UNIT SEPARATOR> Yes
<RESPONSE DATA> Yes
<RESPONSE DATA SEPARATOR> Yes
<NR1 NUMERIC RESPONSE DATA> Yes
<ARBITRARY ASCII RESPONSE DATA> Yes
<RESPONSE HEADER SEPARATOR> No
<RESPONSE HEADER> No
<CHARACTER RESPONSE DATA> Yes
