Standard Event Status Register

Table 2-10. Model of Standard Event Status Register

Bit Definition Implemented?

7 Power On (PON) Yes

6 User Request (URQ) No (always zero)

5 Command ERROR (CME) Yes

4 Execution ERROR (EXE) Yes

3 Device-Specific Error (DDE) Yes

2 Query ERROR (QYE) Yes (only GPIB)

1 Request Control (RQC) No (always zero)

0 Operation Complete (OPC) Yes

Standard Event Status Enable Register

The Standard Event Status Enable Register allows one or more events in the Standard Event Status

Trigger Event Status Register

Table 2-11. Model of Trigger Event Status Register

Bit Definition Implemented?

7 Always zero No

6 Always zero No

5 Always zero No

4 Always zero No

3 Always zero No

2 Always zero No

1 Always zero No

0 Single Wave Enable (SWE) Yes

Trigger Event Status Enable Register

The Trigger Event Status Enable Register allows one or more events in the Standard Event Status Register

to be reflected in the TESB summary-message bit.

2.22 For each command, a statement describing whether it is overlapped or sequential

Overlapped commands are not provided.

2.23 For each command device, the documentation shall specify the functional criteria that are

met when an operation complete message is generated in response to that command.

• Overlapped commands are not provided.

• The operation is completed on receipt of the command.
