3. REMOTE MENU
If the option board is mounted, Remote can be selected from the Utilities menu.
The Remote menu is configured as follows.
• Communication is performed only through the interface selected.
• IP Address, Subnet Mask, and Default Gateway can be set for the IP Address Dialog.
• The IP Address Dialog displays the MAC Address.
Table 3-1. When Interface is set to Off
Menu Function
Interface Off
Not used
Not used
Not used
Not used
Table 3-2. When GPIB is selected as Interface
Menu Function
Interface GPIB
Address GPIB Address
Not used
Not used
Not used
Table 3-3. When TCP/IP is selected as Interface
Menu Function
Interface TCP/IP
IP Address IP Address Menu display function
IP Address Menu cursor down
function
Not used
Enter Sets the current IP Address.
Table 3-4. When USB is selected as Interface
Menu Function
Interface USB
Not Used
Not Used
Not used
Not Used
