MPC2810 Motion Controller Hardware Manual
5
1.5 Typical Control System
A typical motion control system that uses MPC2810 as motion control card is
comprised of:
1) MPC2810 motion control card and breakout board;
2) PC or industrial control computer with PCI slot, Windows2000/XP
operation system;
3) Stepper motor or digital servo motor;
4) Motor drives;
5) Power supplies for motor drives;
6) DC switch power supply, providing +24V power to the breakout
board.
Fig.1-1 Control System using MPC2810
Worktable
Motion Control Card
Breakout Board
Motor Drive
Motor
PC
To Next Page
