MPC2810 Motion Controller Hardware Manual
6
2 Quick Installation
2.1 Check Your Package
Standard package list:
1* MPC2810 motion control card;
1* P62-01 breakout board or 1* P62-02 breakout board;
1* 62-pin shielded cable, 2m;
1* Software toolkit.
Following optional accessories are used for providing more universal I/O
ports if required:
1* C4037 universal I/O extension cable;
1*P37-05 breakout board (matching P62-01 breakout board);
1*37-pin shielded cable, 2m.
2.2 MPC2810/P62-01/P37-05/P62-02 Layout
There are two types of breakout board: P62-01 and P62-02. Only special
input/output signals, such pulse, direction, limits, origin, ramp-down etc., and a
few universal I/O connectors are on the P62-01 board. All motion control card
signals connectors are on the P62-02.
(1) MPC2810 motion control card
4 indicator lights on the back of the board
J1: connect interface for 62-pin shielded cable
J2: connect interface for 40-pin flat cable of universal IO extension cable
Switch: used for setting the local ID of cards if multiple cards are applied.
