MPC2810 Motion Controller Hardware Manual
25
P33 33 IN10 Universal input-10
P14 14 IN11 Universal input-11
P32 32 IN12 Universal input-12
P13 13 IN13 Universal input-13
P31 31 IN14 Universal input-14
P12 12 IN15 Universal input-15
P30 30 IN16 Universal input-16
P11 11 OUT9 Universal output-9
P29 29 OUT10 Universal output-10
P10 10 OUT11 Universal output-11
P28 28 OUT12 Universal output-12
P9 9 OUT13 Universal output-13
P27 27 OUT14 Universal output-14
P8 8 OUT15 Universal output-15
P26 26 OUT16 Universal output-16
P7 7 COM9_16 Protect circuit, connected to +24V
P25 25 DCV24 Output +24V, output current to 200mA
P6 6 OUT17 Universal output-17
P24 24 OUT18 Universal output-18
P5 5 OUT19 Universal output-19
P23 23 OUT20 Universal output-20
P4 4 OUT21 Universal output-21
P22 22 OUT22 Universal output-22
P3 3 OUT23 Universal output-23
P21 21 OUT24 Universal output-24
P2 2 COM17_24 Protect circuit, connected to +24V
P20 20 DCV24 Output +24V, output current to 200mA
P1 1 OGND Output 24V GND
