REPEATER DEPLOYMENT RULES
• A maximum of 6 Repeaters can be configured on an IP-DECT Single Cell Server - RPN 3
• A maximum of 3 Repeaters can be configured in a chain
• If you have up to 3 Repeaters they should be numbered: 67, 131 & 195 i.e. RPN 3 +64, +128 & +192
• If you have more than 3 Repeaters they should be assigned one of the following: 35, 67, 99, 131,
163, 195 & 227
• 2 Repeaters cannot have the same number
• See deployment examples below; RPN = the Radio Part Number
Server is shaded RED Repeaters are shaded GREEN Radio handover BLUE
1 REPEATER DEPLOYMENT
1 Repeater connected directly:
2 REPEATER DEPLOYMENT EXAMPLES
2 Repeaters connected directly:
2 Repeaters connected in a chain:
3 REPEATER DEPLOYMENT EXAMPLES
3 Repeaters connected in a chain:
1 Repeater connected directly and 2 in a chain:
