Leica Digilux 3 User Manual

Others
106
• You can set the aperture value, the shutter
speed and the ISO sensitivity on the
camera even when attaching the external
flash.
• Some commercial external flashes have
synchro terminals with high-voltage or
reversed polarity. Using such external
flashes may cause a malfunction or the
camera may not operate normally.
• If you use commercially available external
flashes with communication functions
other than the dedicated one, they may
not operate normally or they may be
damaged. Do not use them.
• Even if the external flash is turned off,
the camera may enter the external flash
mode when the external flash is
attached. When you are not using the
external flash, detach it or set it to
Forced OFF.
• When attaching the external flash, the
built-in flash cannot be activated.
• Do not open the built-in flash when an
external flash is attached.
• When attaching the external flash, the
camera will become unstable.
• Detach the external flash when carrying
the camera.
• When attaching the external flash, do not
hold only the external flash because it
may detach from the camera.
• If you use the external flash when the
white balance is set to [ ] (Flash) finely
adjust the white balance depending on the
picture quality. (P68)
• If you take pictures close to the subject in
Wide, the vignetting effect may appear on
the bottom of the recorded picture.
• Read the operating instructions of the
external flash for details.
Using Filters
The optional Uva filter (order no. 18 672) is
totally transparent and affects neither color
rendition nor exposure, so it can always
remain on the lens as protection.
The optional polarizing filter (order no.
18 673) can be utilized
1. to darken blue skies and emphasize the
rendition of clouds (by reducing haze), and
2. to reduce or eliminate reflections from all
surfaces except metal (especially on
water), thereby also leading to more
saturated colors.
The effect is controllable by rotating the
filter in its mount, but it also depends on the
angle of the sun and the time of day. Please
take into account that a polarizer reduces
the amount of light, therefore resulting in
longer exposures which may make it
necessary to employ a tripod.
1 Detach the lens cap.

Leica Digilux 3 Specifications

General

Camera type	SLR Camera Body
Sensor type	Live MOS
Image stabilizer	No
Image sensor size	4/3 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3136 x 2352 pixels
Still image resolution(s)	- 3136 x 2352\\r - 2560 x 1020\\r - 2048 x 1536\\r - 3136 x 2080\\r - 2560 x 1712\\r - 2048 x 1360\\r - 3136 x 1760\\r - 1920 x 1080
Optical zoom	1.5 x
Focal length range	2.8 - 3.5 mm
Minimum aperture number	-
Maximum focal length (35mm film equiv)	50 mm
Minimum focal length (35mm film equiv)	14 mm
Focus	TTL
ISO sensitivity	100, 200, 400, 800, 1600, Auto
Light exposure modes	Auto, Manual
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Red-eye reduction, Slow synchronization
External flash connector	Yes
Power source type	Battery
HD type	Not supported
Maximum video resolution	- pixels
Memory slots	1
Internal memory	- MB
Compatible memory cards	MMC, SD, SDHC
Display diagonal	2.5 \
USB version	2.0
White balance	Auto, Daylight, Flash, Halogen, Manual, Outdoor, Shade
Self-timer delay	2, 10 s
Languages support	CZE, DEU, ENG, ESP, FRE, HUN, ITA, JPN
Battery capacity	1500 mAh
Battery life (CIPA standard)	450 shots
Product color	Black, Silver
Storage temperature (T-T)	3136 x 2352 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	80 mm
Width	145.8 mm
Height	86.9 mm
Weight	530 g
