Leica Digilux 3 User Manual

Basic
32
Setting the Focus and
the Exposure
Automatically
(AF: Auto
Focus/Program AE mode [ ])
The camera automatically sets the aperture
value and the shutter speed according to
the brightness of the subject.
• Remove the lens cap.
• Turn the camera on. (P25)
• Set the drive mode lever to [
].
: Shutter button
1 Set the focus mode lever to [AFS].
• AFS is an abbreviation of “Auto Focus
Single”. The focus is fixed when you
press the shutter button halfway.
2 Rotate the shutter speed dial to
[A].
3 Rotate the aperture ring to [A],
while pressing the aperture ring
button .
• The mode becomes program AE mode
[].
4 Aim the AF frame  to the point
you want to focus on and then
press the shutter button halfway.
: Viewfinder Display
• You can check the aperture value 
and shutter speed .
• The camera beeps and the focus
indication  lightswhen the subject is
focused.
• The focus indication blinks when the
subject is not focused. In this case, a
picture is not taken. Press the shutter
button halfway to focus on the subject
again.
• Refer to P34 for information about
subjects that are difficult to focus on.
A
AFS
AFC
AFL
AEL
MF
250
125
60
30
15
8
4
/
B
2-60s
1
000
-
500
A
4
000
A
P
P
STANDARD
STANDARD
ISO
ISO
100
100
AUTO
AUTO
WB
WB
1
SINGLE
SINGLE
NOR
MNORM
CUSTOM
CUSTOM
- 1
+1
+10 - 2 ++2
A
B
CF
ED
G

Leica Digilux 3 Specifications

General

Camera type	SLR Camera Body
Sensor type	Live MOS
Image stabilizer	No
Image sensor size	4/3 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3136 x 2352 pixels
Still image resolution(s)	- 3136 x 2352\\r - 2560 x 1020\\r - 2048 x 1536\\r - 3136 x 2080\\r - 2560 x 1712\\r - 2048 x 1360\\r - 3136 x 1760\\r - 1920 x 1080
Optical zoom	1.5 x
Focal length range	2.8 - 3.5 mm
Minimum aperture number	-
Maximum focal length (35mm film equiv)	50 mm
Minimum focal length (35mm film equiv)	14 mm
Focus	TTL
ISO sensitivity	100, 200, 400, 800, 1600, Auto
Light exposure modes	Auto, Manual
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Red-eye reduction, Slow synchronization
External flash connector	Yes
Power source type	Battery
HD type	Not supported
Maximum video resolution	- pixels
Memory slots	1
Internal memory	- MB
Compatible memory cards	MMC, SD, SDHC
Display diagonal	2.5 \
USB version	2.0
White balance	Auto, Daylight, Flash, Halogen, Manual, Outdoor, Shade
Self-timer delay	2, 10 s
Languages support	CZE, DEU, ENG, ESP, FRE, HUN, ITA, JPN
Battery capacity	1500 mAh
Battery life (CIPA standard)	450 shots
Product color	Black, Silver
Storage temperature (T-T)	3136 x 2352 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	80 mm
Width	145.8 mm
Height	86.9 mm
Weight	530 g
