Leica Digilux 3 User Manual

Preparation
24
w Temporarily storing the lens hood
1 Turn the lens hood in the
direction of the arrow to detach it.
2 Reverse the lens hood and then
attach it in the same way as
shown previously.
• Attach the lens cap.
• When temporarily storing the lens hood,
check that it is firmly attached and that it
does not appear in the picture.
• Hold the short sides of the lens hood
when attaching or detaching it.
• When taking pictures with the flash with
the lens hood attached, the lower portion
of the screen may turn dark (vignetting
effect) and the control of the flash may be
disabled because the flash reflector may
be obscured by the lens hood. We
recommend detaching the lens hood.
• When using the AF assist lamp in the
dark, detach the lens hood.
• For details on how to attach filters refer to
P106.
• For information about optional accesso-
ries, refer to “Accessories“. (P125)
Attaching the Strap
1 Pass the strap through the hole at
the strap eyelet.
: Eyepiece cap
• Attach the strap so that the side with
the eyepiece cap attached to it is near
the Viewfinder.
2 Pass the strap through the
stopper and fasten the strap.
 : Pull the strap 2 cm (0.07 feet) or more.
• Attach the strap to the other side of the
camera also so that is does not get
twisted.
• Check that the strap is firmly attached to
the camera.
• Attach the strap so that the Leica Logo is
on the outside.
A
B

Leica Digilux 3 Specifications

General

Camera type	SLR Camera Body
Sensor type	Live MOS
Image stabilizer	No
Image sensor size	4/3 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3136 x 2352 pixels
Still image resolution(s)	- 3136 x 2352\\r - 2560 x 1020\\r - 2048 x 1536\\r - 3136 x 2080\\r - 2560 x 1712\\r - 2048 x 1360\\r - 3136 x 1760\\r - 1920 x 1080
Optical zoom	1.5 x
Focal length range	2.8 - 3.5 mm
Minimum aperture number	-
Maximum focal length (35mm film equiv)	50 mm
Minimum focal length (35mm film equiv)	14 mm
Focus	TTL
ISO sensitivity	100, 200, 400, 800, 1600, Auto
Light exposure modes	Auto, Manual
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Red-eye reduction, Slow synchronization
External flash connector	Yes
Power source type	Battery
HD type	Not supported
Maximum video resolution	- pixels
Memory slots	1
Internal memory	- MB
Compatible memory cards	MMC, SD, SDHC
Display diagonal	2.5 \
USB version	2.0
White balance	Auto, Daylight, Flash, Halogen, Manual, Outdoor, Shade
Self-timer delay	2, 10 s
Languages support	CZE, DEU, ENG, ESP, FRE, HUN, ITA, JPN
Battery capacity	1500 mAh
Battery life (CIPA standard)	450 shots
Product color	Black, Silver
Storage temperature (T-T)	3136 x 2352 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	80 mm
Width	145.8 mm
Height	86.9 mm
Weight	530 g
