Leica Digilux 3 User Manual

Others
132
The wires in this mains lead are coloured
The rating plate is on the underside of the
in accordance with the following code:
digital camera.
Blue: Neutral
Brown: Live
As the colours of the wires in the mains
lead of this appliance may not
For your safety, please read the following
correspond with the coloured markings
text carefully.
identifying the terminals in your plug,
This appliance is supplied with a moulded
proceed as follows:
three-pin mains plug for your safety and
The wire which is coloured BLUE must
convenience. A 5-ampere fuse is fitted in
be connected to the terminal in the plug
this plug.
which is marked with the letter N or
Should the fuse need to be replaced,
coloured BLACK.
please ensure that the replacement fuse
The wire which is coloured BROWN must
has a rating of 5-amperes and it is
be connected to the terminal in the plug
approved by ASTA or BSI to BS1362.
which is marked with the letter L or
Check for the ASTA mark or the BSI
coloured RED.
mark on the body of the fuse.
Under no circumstances should either of
If the plug contains a removable fuse cover
these wires be connected to the earth
you must ensure that it is refitted when the
terminal of the three-pin plug, marked
fuse is replaced. If you lose the fuse cover,
with the letter E or the Earth Symbol.
the plug must not be used until a
replacement cover is obtained. A
replacement fuse cover can be purchased
Remove the Connector Cover.
from your local Leica Dealer.
IF THE FITTED MOULDED PLUG IS
The location of the fuse differ according to
UNSUITABLE FOR THE SOCKET
the type of AC mains plug (figures A and B).
OUTLET IN YOUR HOME THEN THE
Confirm the AC mains plug fitted and
FUSE SHOULD BE REMOVED AND THE
follow the instructions below.
PLUG CUT OFF AND DISPOSED OF
Illustrations may differ from actual AC
SAFELY.
mains plug.
THERE IS A DANGER OF SEVERE
1) Open the fuse cover with a
ELECTRICAL SHOCK IF THE CUT OFF
screwdriver.
PLUG IS INSERTED INTO ANY 13-
AMPERE SOCKET.
If a new plug is to be fitted, please observe
the wiring code as shown below. If in any
doubt, please consult a qualified
electrician.
2) Replace the fuse and close or attach
the fuse cover.
Fuse cover
Fuse
(5 ampere)
Fuse
(5 ampere)

Leica Digilux 3 Specifications

General

Camera type	SLR Camera Body
Sensor type	Live MOS
Image stabilizer	No
Image sensor size	4/3 \
Supported aspect ratios	3:2, 4:3, 16:9
Maximum image resolution	3136 x 2352 pixels
Still image resolution(s)	- 3136 x 2352\\r - 2560 x 1020\\r - 2048 x 1536\\r - 3136 x 2080\\r - 2560 x 1712\\r - 2048 x 1360\\r - 3136 x 1760\\r - 1920 x 1080
Optical zoom	1.5 x
Focal length range	2.8 - 3.5 mm
Minimum aperture number	-
Maximum focal length (35mm film equiv)	50 mm
Minimum focal length (35mm film equiv)	14 mm
Focus	TTL
ISO sensitivity	100, 200, 400, 800, 1600, Auto
Light exposure modes	Auto, Manual
Light exposure correction	± 2EV (1/3EV step)
Fastest camera shutter speed	1/2000 s
Slowest camera shutter speed	60 s
Flash modes	Auto, Flash off, Red-eye reduction, Slow synchronization
External flash connector	Yes
Power source type	Battery
HD type	Not supported
Maximum video resolution	- pixels
Memory slots	1
Internal memory	- MB
Compatible memory cards	MMC, SD, SDHC
Display diagonal	2.5 \
USB version	2.0
White balance	Auto, Daylight, Flash, Halogen, Manual, Outdoor, Shade
Self-timer delay	2, 10 s
Languages support	CZE, DEU, ENG, ESP, FRE, HUN, ITA, JPN
Battery capacity	1500 mAh
Battery life (CIPA standard)	450 shots
Product color	Black, Silver
Storage temperature (T-T)	3136 x 2352 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %

Weight and Dimensions

Depth	80 mm
Width	145.8 mm
Height	86.9 mm
Weight	530 g
