5.4303.8558.0 -
Maintenance 7-13
Test
1. Tap
.
2. Tap Testing.
3. Tap Induction sensors.
4. Examine Strip status, Sensor status left and Sensor status right. The status indicators must be
green.
5. If one of the indicators is not green, call your local Lely service provider.
Close-up
1. Put the machine into operation.
7.3.12 Test the Barn Door Control Sensors
Connect to the barn door control unit
1. Open the Lely Control Plus app on the smartphone.
2. In the Find machine screen tap
to scan for available devices.
3. Tap the line of the applicable barn door to connect to it. When the machine is connected, the
automatic door screen is displayed.
Test the sensors
1. In the Lely Control Plus app go to Testing. Four test items are displayed:
• Manual mode.
• Induction sensor.
• Relay 1.
• Relay 2.
2. Open and close the door with the Lely Control Plus app. Examine in the Testing menu if at:
• Relay 1 the status indicator turns to green when the door opens.
• Relay 2 the status indicator turns to green when the door closes.
• Induction sensor the status indicator turns to green when the door is open.
3. Turn the Manual mode switch on the barn door control unit to the manual mode position. Examine in
the Testing menu if the status indicator at Manual mode turns to green.
4. Turn the Manual mode switch on the barn door to the automatic mode position.
