5.4303.8558.0 -
6-10 Operating Instructions
• Ultrasound follow R: to follow a wall or fence at the right side of the machine at a distance
of 1.8 (5.9 ft) meter from the wall or fence using ultrasound.
•
Strip follow L: to detect a strip and follow it into the left direction. Approach the strip at a
45 - 90
°
angle and make sure the distance between the strip and the induction sensors is between
30 and 200 cm (12 and 79 in).
•
Strip follow R: to detect a strip and follow it into the right direction. Approach the strip at a
45 - 90
°
angle and make sure the distance between the strip and the induction sensors is between
30 and 200 cm (12 and 79 in).
•
Strip follow F: to detect a strip and to follow it in the forward direction. Approach the strip
in the direction of the strip and make sure the induction sensors are on top of the strip or approach
the strip from a max. distance of 30 cm (12 in).
6.10 Drive the Machine to the Charging Station
Do not drive backwards to the charger. Approach the charger in the
forward direction.
1. Open the Lely Control Plus app on the smartphone.
2. Take the machine out of operation.
3. Manually drive the machine to 0.3 - 2 m (1 - 7 ft) from the strip at the charger station.
4. If the machine:
• must follow the strip to the right direction to reach the charger, tap
Charger drive R.
• must follow the strip to the left direction to reach the charger, tap Charger drive L.
Or:
5. If the machine must follow the strip in the direction of the strip to reach the charger, manually drive
the machine on top of the strip or approach the strip from a max. distance of 0.3 m(1 ft).
6. Tap
Charger drive F.
The machine approaches the charging station and stops by itself.
in n o vato rs in agriculture
