Information for the tester
48
Phase Connection Test
The voltage of the „L“ and „N“ wires is measured with respect to „PE“, evaluated in
the processor and displayed as a phase shift, using the symbol „ "
CAUTION: It must not be assumed that there is no danger in touching the
other wire! The display refers to the larger voltage.
No assignment is possible in position L-N.
In combination with the display of the insulation resistance R
ISO
, the above symbol
indicates the permanently assigned L wire!
Stand-By Mode
After approx. 45 s have elapsed without any operations (keys, central selector), the
instrument goes into stand-by mode automatically. This switching-off serves to
keep down current consumption. „ --- “ appears on the display. All measured
values which appeared before can be recorded with the „DISPLAY“ key.
