16. Diagnostics
Page 62
506457−01 05/10
16. Diagnostics
16.1. M2 Event Codes
When an event occurs, the M2 Unit Controller will display a code which corresponds to control function. See table 40. Error
codes are stored and can be recalled later. See the Installation & Setup Guide For The Prodigy M2 Unit Controller for infor-
mation about viewing and silencing the alarms via the user interface.
Table 40. M2 Event Codes
Code Display Message Action
0
1 ALARM(1) ERRATIC POWER CHECK POWER CONNECTIONS
2 ALARM(2) CHECK SETTINGS
RESET CONTROLLER. CHECK UNIT SETTINGS. CONTACT LENNOX IF
PROBLEM PERSISTS.
3 Reserved
4 ALARM(4) SMOKE A173 SMOKE MODE. CHECK FOR SOURCE OF SMOKE.
5 ALARM(5) BLOWER S52
UNIT OFF. AIR FLOW SWITCH OPEN 16 SEC AFTER DEMAND. CHECK
BLOWER PARTS
6 ALARM(6) FILTER S27 REPLACE FILTER OR CHECK FILTER SWITCH S27
7 ALARM(7) CONTROLLER PROBLEM
RESET CONTROLLER. CHECK UNIT SETTINGS. CONTACT LENNOX IF
PROBLEM PERSISTS.
8
ALARM(8) STRIKE 3 ON BLOWER
S52
LOCKOUT. MULTIPLE CODE 5. CHECK BLOWER PARTS
9 − 11 Reserved
12 ALARM(12) COMP 1 HIGH PRESS S4 COMP OFF. CHECK CHARGE, FANS, COIL.
13
ALARM(13) STRIKE 3 ON COMP 1
HIGH PRESS S4
COMP LOCKOUT. CHECK CHECK CHARGE, FANS, COIL. USE SERVICE
MENU TO CLEAR LOCKOUTS.
14 ALARM(14) COMP 2 HIGH PRESS S7 COMP OFF. CHECK CHARGE, FANS, COIL.
15
ALARM(15) STRIKE 3 ON COMP 2
HIGH PRESS S7
COMP LOCKOUT. CHECK CHECK CHARGE, FANS, COIL. USE SERVICE
MENU TO CLEAR LOCKOUTS.
16
ALARM(16) COMP 3 HIGH PRESS
S28
COMP OFF. CHECK CHARGE, FANS, COIL.
17
ALARM(17) STRIKE 3 ON COMP 3
HIGH PRESS S28
COMP LOCKOUT. CHECK CHARGE, FANS, COIL. USE SERVICE MENU
TO CLEAR LOCKOUTS.
18
ALARM(18) COMP 4 HIGH PRESS
S96
COMP OFF. CHECK CHARGE, FANS, COIL.
19
ALARM(19) STRIKE 3 ON COMP 4
HIGH PRESS S96
COMP LOCKOUT. CHECK CHECK CHARGE, FANS, COIL. USE SERVICE
MENU TO CLEAR LOCKOUTS.
NOTE − Alarms 12−19 could also be caused by a high temperature condition on some compressors equipped with a high temperature shutdown.
20 ALARM(20) UNIT SHUTDOWN A42 CHECK PHASE MONITOR
21
ALARM(21) STRIKE 3 UNIT SHUT-
DOWN A42
CHECK PHASE MONITOR
22
ALARM(22) COMP 1 LOW PRESS
S87
COMP OFF. CHECK CHARGE, FILTERS, AIR FLOW. COIL
23
ALARM(23) STRIKE 3 ON COMP 1
S87
COMP LOCKOUT. CHECK CHECK CHARGE, FILTER, AIR FLOW, COIL.
USE SERVICE MENU TO CLEAR LOCKOUTS.
24
ALARM(24) COMP 2 LOW PRESS
S88
COMP OFF. CHECK CHARGE, FILTERS, AIR FLOW. COIL
25
ALARM(25) STRIKE 3 ON COMP 2
S88
COMP LOCKOUT. CHECK CHECK CHARGE, FILTER, AIR FLOW, COIL.
USE SERVICE MENU TO CLEAR LOCKOUTS.
26
ALARM(26) COMP 3 LOW PRESS
S98
COMP OFF. CHECK CHARGE, FILTERS, AIR FLOW. COIL
27
ALARM(27) STRIKE 3 ON COMP 3
S98
COMP LOCKOUT. CHECK CHECK CHARGE, FILTER, AIR FLOW, COIL.
USE SERVICE MENU TO CLEAR LOCKOUTS.
28
ALARM(28) COMP 4 LOW PRESS
S97
COMP OFF. CHECK CHARGE, FILTERS, AIR FLOW. COIL
29
ALARM(29) STRIKE 3 ON COMP 4
S97
COMP LOCKOUT. CHECK CHECK CHARGE, FILTER, AIR FLOW, COIL.
USE SERVICE MENU TO CLEAR LOCKOUTS.
30 ALARM(30) UNIT SHUTDOWN S149 CHECK OVERFLOW SW
table continued on next page
