Chapter 7. Locations
This chapter introduces the locations of the hardware components on your computer.
Locating computer controls, connectors, and indicators
This topic introduces the locations of the computer controls, connectors, and indicators.
Front view
1 Camera
2 Microphones
3 TrackPoint
®
pointing stick 4 Power button
5 Numeric keypad
6 Fingerprint reader (available on some models)
7 TrackPoint buttons 8 Trackpad
Left-side view
1 USB-C™ connector
2 HDMI™ connector
3 Always On USB 3.1 connector Gen 1 4 USB 3.1 connector Gen 1
5 Audio connector
© Copyright Lenovo , 2017 51
