Lenovo ThinkPad E585 - 2020 LCD Panel

Removal steps of the LCD bezel
When installing: Ensure that all the latches are attached firmly.
2020 LCD panel
For access, remove these FRUs in order:
• “1150 LCD unit” on page 88
• “2010 LCD bezel” on page 89
Removal steps of the LCD panel
Step Screw (quantity) Color Torque
1
M2 × 3 mm, wafer-head, nylon-coated, small head (4) Black 0.294 Nm
(3 kgf-cm)
90 ThinkPad E580 and E585 Hardware Maintenance Manual
