1010 Base cover assembly
Removal steps of the bottom cover
Loosen the screws
1 and then remove the bottom cover 2 .
Applying labels to the base cover assembly
Note: Depending on the country or region of delivery, the labels might be slightly different from the ones in
the following illustration.
Chapter 9. Removing or replacing a FRU 69
