Lenovo ThinkPad E585 - Right-Side View; Bottom View; Locating Frus and Crus

Right-side view
1 MicroSD card slot 2 USB 2.0 connector
3 Ethernet connector
4 Security-lock slot
Bottom view
1 Fan louvers
2 Speakers
Locating FRUs and CRUs
This topic introduces the following service parts:
• “Major FRUs and CRUs” on page 54
• “LCD FRUs and CRUs” on page 56
52
ThinkPad E580 and E585 Hardware Maintenance Manual
