When installing: Ensure that the connector is attached firmly.
1090 Keyboard
For access, remove these FRUs in order:
• “1010 Base cover assembly” on page 69
Removal steps of the keyboard
Note: Depending on the model, your computer might look different from the illustrations in this topic.
Step Screw (quantity) Color
Torque
1
M2 × 3mm, flat-head, nylon-coated (1)
Black 0.294 Nm
(3 kgf-cm)
Chapter 9. Removing or replacing a FRU 77
