Chapter4.Locatingparts,controls,LEDs,andconnectors
Thischapterprovidesinformationtohelpyoulocateyourserverparts,controls,light-emittingdiodes
(LEDs),andconnectors.
Frontview
Thefollowingillustrationshowsthedrivesandpartsonthefrontoftheserver.
Figure1.Frontviewoftheserverwitheightharddiskdrivesandanopticaldrive
1Lefthandleofthechassis
4Opticaldrive
23.5-inchharddiskdrivebay
5Frontcontrolpanel(see“Frontcontrolpanel”onpage10)
33.5-inchharddiskdrivedummy
bay
Rearview
Thefollowingillustrationshowsthelocationsoftheconnectorsandpartsontherearoftheserver.
Figure2.Rearviewoftheserver
1Powersupply1
6Serialport
2Powersupply2bay(blankand
coveredbyabaybezel)
7USBconnectors(3and4)
3Powercordconnector8Ethernetconnector1
©CopyrightLenovo2010,2011
9
