Removingtheopticaldrive
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstandingthe“Safetyinformation”
onpageiiiand“Guidelines”onpage17.
Thissectionprovidesinstructionsonhowtoremovetheopticaldrive.
Toremovetheopticaldrive,dothefollowing:
1.Removeallmediafromthedrivesandturnoffallattacheddevicesandtheserver.Then,disconnectall
powercordsfromelectricaloutletsanddisconnectallcablesthatareconnectedtotheserver.
2.Removetheservercover.See“Removingtheservercover”onpage19.
3.Thereisonescrewoneachsideandtwoscrewsonthetop.Removethefourscrewsthatsecurethe
driveaccesspanel1.Slidethedriveaccesspanelbackandliftittoremoveit2.
Figure12.Removingthedriveaccesspanel
4.Disconnectthepowercableandthesignalcablefromtherearoftheopticaldrive.
