Lenovo ThinkServer 1045 - Front Control Panel

4USBconnectors(1and2)9Ethernetconnector2(sharewithMGMT)
5VGAmonitorconnector10PCIexpansionslot
ConnectorDescription
PowercordconnectorUsedtoconnectthepowercord.
Ethernetconnector
UsedtoattachanEthernetcableforalocalareanetwork(LAN).
Serialport
Usedtoattachadevicethatusesa9-pinserialport.
USBconnectorUsedtoattachadevicethatusesaUSBconnector,suchasaUSBkeyboard
oraUSBmouse.
VGAmonitorconnectorUsedtoattachaVGAmonitororotherdevicesthatuseaVGAmonitorconnector.
Frontcontrolpanel
Thissectionprovidesinformationaboutthefrontcontrolpaneloftheserver.
Thefollowingillustrationhelpsyouidentifytheconnectors,controls,andLEDsonthefrontcontrolpanelof
yourserver.
Figure3.Frontcontrolpanel
1IDbuttonandLED4Ethernet2statusLED
2SystemstatusLED
5PowerbuttonandLED
3Ethernet1statusLED
