1J51(forconnectingtheSGPIOconnectorofthemini
SAScable)
3SASconnectors(top:SAS3;bottom:SAS2)
2SASconnectors(top:SAS1;bottom:SAS0)
WhenconnectingharddiskdrivestothesystemboardusingtheminiSAScable,connecttheminiSAS
connector
4totheminiSASconnectoronthebackplane.ConnectthefourSASconnectors6,7,8,and
9totheSASconnectors0,1,2,and3onthesystemboard.Then,connecttheSGPIOconnector5to
theJ51connectoronthesystemboard.
Notes:
•RemoveanydevicethatmightpreventyoufromconnectingtheminiSAScabletothesystemboard.
•Forthelocationofthemini-SASsignalcableconnectoronthebackplane,referto“Locatingconnectors
onthebackplane”onpage16.
Figure63.MiniSAScablewithfourSASconnectorsandoneSGPIOconnector
Note:ThenumberonthelabelforeachofthefourSASsignalcablesindicatesthesequencewhenyouare
connectingthecablestothecorrespondingSASconnectors(0-3)onthesystemboard.
SASconnectorSASsignalcablelabelSystemboardSASconnector
6
P1
SASconnector0
7
P2
SASconnector1
8
P3
SASconnector2
9
P4
SASconnector3
StartingtheCongurationUtilityprogram
DuringthePOST,whenthemessage“PressCtrl-CtostartLSILogiccongurationUtility...”isdisplayed,press
Ctrl+CtoentertheCongurationUtilitymainmenu.PressEnterandtheAdapterListwindowisdisplayed.In
thiswindow,youcanviewthecontrollerlist,viewtheharddiskdriveinformation,andcongureRAID.
Whenworkingwiththisprogram,youmustusethekeyboard.Thekeysusedtoperformvarioustasksare
displayedatthebottomofeachscreen.
Table27.ItemsintheAdapterListwindow
ItemDescription
Adapter
TheSASadapter(s)detected
PCIBusThePCIbusnumberassignedtotheadapter
Dev/FncThePCIdeviceorfunctionassignedtotheadapter
