ToinstallthebatterycardassemblyontotheRAIDcontroller,dothefollowing:
a.Notethebottomviewofthebatterycardassembly.
Figure43.Bottomviewofthebatterycardassembly
1J1board-to-boardconnector
2J2remoteconnector(reservedforuse)
b.Withthefrontsideup,placetheRAIDcontrolleronaat,clean,static-freesurface.
c.HoldthebatterycardassemblywiththebatterysideupandtheJ1board-to-boardconnector
liningupwiththeJ6B1BBUconnector
1ontheRAIDcontroller.Carefullypressthebatterycard
assemblyontotheRAIDcontrollersothatthetwoconnectorsarermlyjoined.Then,securethe
batterycardassemblytotheRAIDcontrollerwiththethreescrewsandthestandoffsthatcome
withthebatterycardassemblyaccessorykit.
Figure44.InstallingthebatterycardassemblyontotheRAIDcontroller
1J6B1BBUconnector
Chapter5.Installing,removing,orreplacinghardware51
