1 - 4 Screws
5 Air flow
6 The front of the chassis
5. If you are instructed to return the heat sink, follow all packaging instructions
and use any packaging materials that are supplied to you for shipping.
What to do next:
v To install the heat sink, see “Installing the heat sink.”
v To work with another piece of hardware, go to the appropriate section.
Installing the heat sink
Attention
Do not open your server or attempt any repair before reading and understanding the Safety
Information and the Warranty and Support Information on the ThinkServer Documentation DVD
that comes with your product, and “Guidelines” on page 19. To obtain a copy of the
publications, go to:
http://www.lenovo.com/support
This section provides instructions on how to install the heat sink.
Figure 44. Removing the heat sink
Chapter 5. Installing, removing, or replacing hardware 61
