Table 14. Submenus under the CPU Configuration (continued)
Item Option Description
ACPI T State Disabled
[Enabled]
Enable or disable the
microprocessor throttling in
ACPI.
Notes:
1. The settings in[]arethedefault settings in the Setup Utility program.
2. The above options might vary depending on the type of the installed microprocessor.
Table 15. Submenus under the Mass Storage Controller Configuration
Item Option Description
SATA Configuration Disabled
[Enabled]
Enable or disable the
integrated SATA controller.
Configure SATA as [IDE]
RAID
To select the hard disk drive
mode. If this option is set to
IDE, all the SATA connectors
will be configured as
stand-alone SATA connectors.
Notes:
1. The settings in[]arethedefault settings in the Setup Utility program.
2. The SATA Configuration item might not apply because your server came with an
integrated SAS controller.
Table 16. Submenus under the SuperIO Configuration
Item Option Description
Serial Port1 Address Disabled
[3F8/IRQ4]
3E8/IRQ4
2E8/IRQ3
Select the I/O base address
and interrupt for serial port
1.
Serial Port2 Address Disabled
[2F8/IRQ3]
3E8/IRQ4
2E8/IRQ3
Select the I/O base address
and interrupt for serial port
2.
Note: The settings in[]arethedefault settings in the Setup Utility program.
Table 17. Submenus under the USB Configuration
Item Option Description
Legacy USB Support Disabled
[Enabled]
Auto
Enable or disable the support
on legacy USB devices.
USB 2.0 Controller Mode FullSpeed
[HiSpeed]
Select the USB speed.
Hotplug USB FDD Support Disabled
Enabled
[Auto]
Enable or disable the support
on the hot-swap USB
diskette drive.
Note: The settings in[]arethedefault settings in the Setup Utility program.
For external USB devices, the USB Mass Storage Device Configuration submenu is as
below:
Chapter 6. Configuring the server 75
