6.LocatetheRAID5keyconnectorontheThinkServerRAID500Adapterandthencarefullyinsertthe
TR500Keyintotheconnector.Ifnecessary,youcanremovetheThinkServerRAID500Adapterfirst,
installtheTR500Keyonit,andthenreinstalltheThinkServerRAID500Adapter.See“Installingor
removingtheRAIDcard”onpage107
.
Note:EnsurethattheTR500KeyissecurelyseatedontheThinkServerRAID500Adapter.
Figure67.InstallingtheTR500Key
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallation,goto“Completingthepartsreplacement”onpage206
.Then,thehardware
RAID5andRAID50areavailableforyourserverifyourserverhastherequirednumberofharddiskdrives
installed.RefertotheMegaRAIDSASSoftwareUserGuideonthedocumentationDVDthatcomeswith
yourserverforinformationabouthowtoconfigurethehardwareRAID.
RemovingtheTR500Key
Attention:Donotopenyourserverorattemptanyrepairbeforereadingandunderstanding“Safetyinformation”
onpageiiiand“Guidelines”onpage87.
ThistopicprovidesinstructionsonhowtoremovetheTR500KeyifyourserverhasaThinkServerRAID
500AdapterwithaTR500Keyoptioninstalled.
Attention:BackupyourdatabeforeyoubeginifyouneedtoreconfigureRAIDandreinstalltheoperating
systemafterremovingtheTR500Key.
Beforeyoubegin,printalltherelatedinstructionsorensurethatyoucanviewthePDFversiononanother
computerforreference.
Notes:
•IfyouremovetheTR500Key,thehardwareRAID5andRAID50willbedisabled.
•UseanydocumentationthatcomeswiththeTR500Keyandfollowthoseinstructionsinadditionto
theinstructionsinthistopic.
ToremovetheTR500Key,dothefollowing:
