7SASconnector4-723Systemfan6connector
8SASconnector0-3
24Microprocessorsocket2
9Coin-cellbattery25Systemfan5connector
10PlatformControllerHub(PCH)26Memoryslots(6)
11InternalUSBTypeAconnector227Systemfan3connector
12TMMPremiumconnector28Microprocessorsocket1
13InternalUSBTypeAconnector129Systemfan2connector
14TPMconnector
30Memoryslots(6)
15iButtonsocket
31Systemfan1connector
16ThinkServerManagementModule
1Frontpanelconnector
Usedtoconnectthefrontpanelcableifyourserverhasafrontpanelboardinstalled.
2InternalUSBconnector1
UsedtoconnectthefrontpanelUSBcableifyourserverhasafrontpanelboardinstalled.
3InternalUSBconnector2
Reservedforthemanufacturer.
4Diagnosticmoduleconnector
Usedtoconnectthecableofthediagnosticmoduleifyourserverhasadiagnosticmoduleinstalled.
5FrontVGAconnector
UsedtoconnectthecableoftheVGADB-15connectoronthefrontpanelofsomeservermodels.
6SATAconnector0
Usedtoconnectthesignalcableoftheslimopticaldriveifyourserverhasaslimopticaldriveinstalled.
7SASconnector4-7
Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive4toharddiskdrive7.
8SASconnector0-3
Usedtoconnectthemini-SASconnectorononeendofamini-SAStomini-SASsignalcabletosupportthe
harddiskdrive0toharddiskdrive3.
9Coin-cellbattery
Yourserverhasaspecialtypeofmemorythatmaintainsthedate,time,andconfigurationinformationfor
built-infeatures.Thecoin-cellbatterykeepstheinformationactivewhenyouturnofftheserver.
