4Slimopticaldrive
SomeservermodelscomewithaslimSATAopticaldrive.
5Rackhandle(left)
8Rackhandle(right)
Ifyourserverisinstalledinarackcabinet,youcanusetherackhandlestohelpyouslidetheserverout
oftherackcabinet;orusetherackhandlesandscrewstosecuretheserverintherackcabinetsothat
theservercannotslideout,especiallyinvibration-proneareas.Formoreinformation,refertotheRack
InstallationInstructionsthatcomeswithyourserver.
6Diagnosticpanel
Thediagnosticpanelvariesbymodel.Fordetailedinformation,see“Diagnosticmodule”onpage24.
7Frontpanel
Fordetailedinformationaboutthecontrols,connectors,andstatusLEDsonthefrontpanel,see“Front
panel”onpage22.
Frontpanel
Thistopicappliesonlytothefollowingservermodels:
•Servermodelswitheight3.5-inchhard-disk-drivebays
•Servermodelswith2.5-inchhard-disk-drivebays
Forservermodelswithtwelve3.5-inchhard-disk-drivebays,thefrontUSBconnectorsareintegratedinto
theleftrackhandle;andthefrontcontrolsandLEDsareintegratedintotherightrackhandle.See“Front
viewofservermodelswithtwelve3.5-inchhard-disk-drivebays”onpage18fordetailedinformation.
Thefollowingillustrationshowsthecontrols,connectors,andLEDsonthefrontpaneloftheserver.Tolocate
thefrontpanel,see“Frontviewofservermodelswitheight3.5-inchhard-disk-drivebays”onpage17and
“Frontviewofservermodelswith2.5-inchhard-disk-drivebays”onpage21.
ID
Figure11.Frontpanel
1PowerbuttonwithpowerstatusLED
5SystemerrorLED
2IDbuttonwithIDLED
6FrontUSBconnectors(2)
3NIC1statusLED7VGADB-15connector
4NIC2statusLED
