ThinkServerRAID710Adapter(alsoknownas9270CV-8iRAIDadapter)
ThefollowingillustrationshowstheconnectorsontheThinkServerRAID710Adapter.
Figure27.ThinkServerRAID710Adapter
1Port1
3ThinkServerRAIDSuperCapacitorModuleconnector
2Port2
1Port1
Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage48.
2Port2
Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage48.
3ThinkServerRAIDSuperCapacitorModuleconnector
UsedtoconnectthecableofaThinkServerRAIDSuperCapacitorModule.See“Installingorreplacingthe
ThinkServerRAIDSuperCapacitorModuleonthecoolingshroud”onpage166.
Expandercard
Thistopicprovidesinformationtohelpyoulocatetheconnectorsontheexpandercardifyourserverhas
oneinstalledintheshorterslotoftherisercardassembly1.
TheexpandercardworkstogetherwiththeRAIDcardbyexpandingtheportsontheRAIDcardsothat
theservercansupportupto16harddiskdrives.
Note:TheservermusthaveaRAIDcardandanexpandercardinstalledtosupportmorethaneighthard
diskdrives.
