ThinkServerRAID700Adapter(alsoknownasThinkServer9260-8iSASRAIDAdapter)
ThefollowingillustrationshowstheconnectorsontheThinkServerRAID700Adapter.
Figure26.ThinkServerRAID700Adapter
1Ports7-4
3ThinkServerRAID700Batteryconnector
2Ports3-0
1Ports7-4
Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage48
.
2Ports3-0
Usedtoconnectamini-SASsignalcable.See“Connectingthecables”onpage48
.
3ThinkServerRAID700Batteryconnector
UsedtoconnectaThinkServerRAID700Battery.See“InstallingorremovingtheThinkServerRAID700
Battery”onpage113.
42ThinkServerRD440UserGuideandHardwareMaintenanceManual
