Chapter7.Troubleshootinganddiagnostics
Thischapterprovidesinformationaboutbasictroubleshootinganddiagnosticmethodstohelpyousolve
problemsthatmightoccurintheserver.
Ifyoucannotdiagnoseandcorrectaproblembyusingtheinformationinthischapter,seeChapter8
“Gettinginformation,help,andservice”onpage217foradditionaltroubleshootingresources.
Troubleshootingprocedure
Usethefollowinginformationasageneralprocedurefordiagnosingandtroubleshootingproblemsyou
experiencewithyourserver:
1.Verifythatthepowercordsandthecablesforallattacheddevicesareconnectedcorrectlyandsecurely.
2.Verifythattheserverandallattacheddevicesthatrequireacpowerareconnectedtoproperlygrounded,
functioningelectricaloutlets.
3.VerifythatallinstalledhardwareandattacheddevicesareenabledintheBIOSsettingsofyourserver.
FormoreinformationaboutaccessingandchangingtheBIOSsettings,see“UsingtheSetupUtility
program”onpage65
.
4.ViewthestatusanddiagnosticLEDstoidentifythesystemanddevicestatusanddiagnoseproblems.
See“ViewingthestatusanddiagnosticLEDs”onpage211.
5.Iftheserverisnotworkingafteryouhaveaddednewsoftware,installedanewoptionaldevice,or
replacedapieceofhardware,removeorreinstallthesoftware,device,orhardwaretoseeiftheproblem
couldbesolved.
6.Viewthesystemeventlogtodiagnoseproblems.See“Viewingthesystemeventlog”onpage212.
7.TurnontheserverandpressEscassoonasyouseethelogoscreentoviewanydiagnosticmessages.
8.Downloadanduseadiagnosticprogramtodiagnoseproblems.See“Usingadiagnosticprogram”on
page212.
9.Referto“Basictroubleshootingtables”onpage212andfollowtheinstructionsforthetypeofproblem
youareexperiencing.Ifthebasictroubleshootinginformationdoesnothelpyouresolveaproblem,
continuewiththenextstep.
10.Tryusingapreviousserverconfigurationtoseeifarecentchangetohardwareorsoftwaresettingshas
causedaproblem.Beforerestoringyourpreviousconfiguration,captureyourcurrentconfigurationin
casetheolderconfigurationsettingsdonotsolvetheproblemorhaveadverseeffect.
11.Useanantivirusprogramtoseeifyourserverhasbeeninfectedbyavirus.Iftheprogramdetectsa
virus,removethevirus.
12.Ifnoneoftheseactionssolvetheproblem,seektechnicalassistance.SeeChapter8“Getting
information,help,andservice”onpage217.
ViewingthestatusanddiagnosticLEDs
YourserverhasstatusanddiagnosticLEDsonthefrontandrearofthechassis,thesystemboard,the
hot-swapharddiskdrives,thehot-swapredundantpowersupplies,andtheopticaldrive(somemodels).
ThevariousLEDshelpyoueasilyidentifythesystemanddevicestatusanddiagnoseproblems.For
informationabouttheLEDs,refertotherelatedtopicsin“Locations”onpage14.
©CopyrightLenovo2013,2014
211
