9.Removetheprotectivecoverthatprotectsthegoldcontactsonthebottomofthenewmicroprocessor.
Donottouchthepinsonthemicroprocessorsocketandthegoldcontactsonthebottomofthenew
microprocessor.
Figure92.Donottouchthepins
10.Notetheorientationofthenewmicroprocessor.Holdthenewmicroprocessorbyitsedgesandalign
thenotches
1onitwiththetabs2inthemicroprocessorsocket.Then,carefullylowerthenew
microprocessorstraightdownintothemicroprocessorsocket.
Note:Thesmalltriangle3ononecornerofthenewmicroprocessoristhemicroprocessororientation
indicator.Thenewmicroprocessorisinthecorrectorientationwhenthisindicatorfacesthebeveled
corner4ofthemicroprocessorsocket.
Figure93.Installingthemicroprocessor
144ThinkServerRD440UserGuideandHardwareMaintenanceManual
