7.Ensurethatthesmallhandleandthemicroprocessorretainerareinthefullyopenposition.Touchonly
theedgesofthemicroprocessorandcarefullyliftitstraightupandoutofthemicroprocessorsocket.
Placetheoldmicroprocessoronastatic-protectivesurface.
Notes:
•Donottouchthegoldcontactsonthebottomofthemicroprocessor.
•Donotdropanythingontothemicroprocessorsocketwhileitisexposed.Thesocketpinsmustbe
keptascleanaspossible.
Figure96.Removingthemicroprocessor
8.Touchthestatic-protectivepackagethatcontainsthenewmicroprocessortoanyunpaintedsurfaceon
theoutsideoftheserver.Then,removethenewmicroprocessorfromthepackage.
9.Removetheprotectivecoverthatprotectsthegoldcontactsonthebottomofthenewmicroprocessor.
Donottouchthepinsonthemicroprocessorsocketandthegoldcontactsonthebottomofthenew
microprocessor.
Figure97.Donottouchthepins
Chapter6.Installing,removing,orreplacinghardware147
