6.Pressthereleasetab1inthedirectionasshownandthenpushthediagnosticmoduleoutofthe
frontofthechassis.
Figure154.Removingthediagnosticmoduleforservermodelswitheight3.5-inchhard-disk-drivebays
7.Touchthestatic-protectivepackagethatcontainsthenewdiagnosticmoduletoanyunpaintedsurface
ontheoutsideoftheserver.Then,takethenewdiagnosticmoduleoutofthepackage.
8.Slidethenewdiagnosticmoduleintothechassisfromthefrontuntilitsnapsintoposition.
Figure155.Installingthediagnosticmoduleforservermodelswitheight3.5-inchhard-disk-drivebays
9.Connectthediagnosticmodulecabletotherearofthenewdiagnosticmodule.
192ThinkServerRD440UserGuideandHardwareMaintenanceManual
