23.Notetheorientationofthepowersupplycoolingshroudandinstallitintothechassisbyinsertingthe
twosmalltabs
1onthebottomoftheshroudintothecorrespondingholes2inthepowersupplycage.
Figure170.Installingthepowersupplycoolingshroud
24.Installthecoin-cellbatteryonthenewsystemboard.See“Replacingthecoin-cellbattery”onpage196.
25.IfyouhaveaTMMPremium,installtheTMMPremiumonthenewsystemboard.See“Installingthe
TMMPremium”onpage129.
26.IfyouhaveaTPM,installtheTPMonthenewsystemboard.See“InstallingtheTPM”onpage132.
27.Installthetworisercardassembliesonthenewsystemboard.See“Replacingtherisercardassembly
1”onpage183and“Replacingtherisercardassembly2”onpage185.
28.Notetheorientationofthesystemfancage.Aligntheleftandrightsidesofthesystemfancagewiththe
correspondingmountingpostsinthechassis.Then,pressthesystemfancagewiththeinstalledsystem
fansstraightdownintothechassisuntilthesystemfancageiscorrectlyseatedandthesystemfansare
correctlyconnectedtothesystemfanconnectorsonthesystemboard.
ID
PSU
Mem
CPU
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Figure171.Installingthesystemfancagewithsystemfans
29.Installanyotherpartsthatyouhaveremovedandconnectallcablestothenewsystemboard.Refer
totheinformationthatyouhaverecordedandtherelatedtopicsin“Installing,removing,orreplacing
hardware”onpage92.
Chapter6.Installing,removing,orreplacinghardware205
