Figure21.Componentsofservermodelswithtwelve3.5-inchhard-disk-drivebays
1Coolingshroud
10Hot-swaphard-disk-drivebackplane
2Powersupplycoolingshroud
11Systemfans(5)
3Risercardassembly2
12CPU1DIMMs(varybymodel)
4Oneortwohot-swapredundantpowersupplies13CPU2DIMMs(varybymodel)
5PCIExpresscards(availableinsomemodels)14Systemboard
6Heatsinkswithmicroprocessorsunderneath
15Coin-cellbattery
7Rackhandle(right)withfrontcontrolsandLEDs
16Expandercard
83.5-inchhard-disk-drivearea17RAIDcard
9Rackhandle(left)withfrontUSBconnectors
18Risercardassembly1
36ThinkServerRD440UserGuideandHardwareMaintenanceManual
