Figure 22. Connectors on SATA/SAS RAID adapter (16i)
Table 18. SATA/SAS RAID adapter (16i)
1 SATA/SAS RAID adapter (16i) with four SATA/SAS connectors (C0, C1, C2, C3)
Figure 23. Connectors on PCIe switch card
Table 19. PCIe switch card
1 PCIe switch card with four SATA/SAS connectors (C0, C1, C2, C3)
Internal cable routing
This section provides information about routing the cables when you install components in the server.
For more information about the requirements for cables and connecting devices, see the documentation that
comes with these devices.
Guideline for cable routing for 2.5-inch drives
General guideline for cable routing for 2.5-inch drives.
1. Make sure all the signal cables go through the cable guides.
