Table 51. Memory mirroring with four processors (processor 3 and 4)
Total Processor 3 Processor 4 Total
DIMMs 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 DIMMs
8 32 34 44 46 8
10 32 34 36 44 46 10
12 27 29 32 34 44 46 12
14 27 29 32 34 44 46 48 14
16 27 29 32 34 39 41 44 46 16
18 27 29 32 34 39 41 44 46 18
20 25 27 29 32 34 36 39 41 44 46 20
22 25 27 29 32 34 36 39 41 44 46 22
24 25 27 29 32 34 36 37 39 41 44 46 48 24
26 25 27 29 32 34 36 37 39 41 44 46 48 26
28 25 27 29 32 34 36 37 39 41 44 46 48 28
30 27 28 29 30 31 32 33 34 37 39 41 44 46 48 30
32 27 28 29 30 31 32 33 34 39 40 41 42 43 44 45 46 32
34 27 28 29 30 31 32 33 34 37 39 41 44 46 48 34
36 25 27 29 32 34 36 37 39 41 44 46 48 36
38 27 28 29 30 31 32 33 34 37 39 41 44 46 48 38
40 27 28 29 30 31 32 33 34 39 40 41 42 43 44 45 46 40
42 25 26 27 28 29 30 31 32 33 34 35 36 37 39 41 44 46 48 42
44 25 26 27 28 29 30 31 32 33 34 35 36 39 40 41 42 43 44 45 46 47 48 44
48 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 10 41 42 43 44 45 46 47 48 48
Related DIMM population sequences for four processor systems:
• To continue populating processor 1 and 2 DIMMs, see
Table 50 “Memory mirroring with four processors
(Processor 1 and 2)” on page 70
.
Chapter 3. Server hardware setup 71
